ELECTRO-VOICE ELX200-15P 15" 2-Way Class D Active Speaker 1200W Black
Product Overview
The Electro-Voice ELX200-15P is a professional 15-inch 2-way powered loudspeaker designed for live sound, mobile DJs, musicians, venues, installations, and portable PA applications. Featuring a high-efficiency 1200W Class-D amplifier, EVS-15M low-frequency driver, and advanced QuickSmart DSP processing, the ELX200-15P delivers powerful output with excellent clarity and reliability.
Equipped with a DH-1L titanium compression driver and Signal Synchronized Transducers (SST) waveguide technology, the ELX200-15P provides consistent coverage, reduced distortion, and detailed high-frequency performance. The integrated DSP system offers speaker presets, EQ control, crossover selection, limiter monitoring, and professional system optimisation.
Built with a lightweight and durable polypropylene enclosure, steel grille, integrated pole mount, M10 suspension points, and QuickSmart Mobile wireless control, the ELX200-15P is ideal for professional portable sound systems, DJs, bands, events, and installed audio applications.
Key Features
15" Two-Way System
Professional full-range speaker with powerful low-frequency response.
1200W Class-D Amplifier
High-efficiency amplification for professional sound reinforcement.
QuickSmart DSP
Advanced DSP with presets, EQ, crossover and limiter monitoring.
EVS-15M Woofer
15-inch high-output driver engineered for durability and performance.
DH-1L Compression Driver
Titanium high-frequency driver for clear and detailed sound.
Wireless Control
QuickSmart Mobile Bluetooth Low Energy remote management.
Technical Specifications
| Product Type | Active 2-Way Full Range Loudspeaker |
|---|---|
| Woofer Size | 15" EVS-15M Low Frequency Driver |
| High Frequency Driver | 1" DH-1L Titanium Compression Driver |
| Amplifier Type | Class-D Integrated Amplifier |
| Power Rating | 1200W |
| Frequency Response | 55Hz - 16kHz (-3dB) |
| Frequency Range | 48Hz - 19kHz (-10dB) |
| Maximum SPL | 132dB |
| Coverage Pattern | 90° x 60° |
| Crossover Frequency | 1600Hz |
| DSP Processing | QuickSmart DSP with Presets, EQ, Crossover and Limiter Monitoring |
| Speaker Presets | Music / Live / Speech / Club |
| Wireless Control | QuickSmart Mobile Bluetooth Low Energy Control |
| Inputs |
2 x XLR/TRS Combo Inputs 1 x Stereo RCA Input |
| Output | 1 x XLR Link Output |
| Enclosure Material | Polypropylene Composite Cabinet |
| Grille | 18 AWG Steel with Powder Coat Finish |
| Mounting | 35mm Pole Mount + 3 x M10 Suspension Points |
| Power Supply | 100-240V AC, 50-60Hz |
| Dimensions (H x W x D) | 710 x 423 x 384mm |
| Weight | 18.9kg |
| Colour | Black |
Ideal For
- Mobile DJs
- Live Bands
- Concert Events
- Wedding Production
- Corporate Events
- Houses of Worship
- Portable PA Systems
- Stage Monitoring
- Professional Venues
- Installed Sound Systems
