ELECTRO-VOICE ELX200-10P 10" 2-Way Class D Active Speaker 1200W Black
Product Overview
The Electro-Voice ELX200-10P is a professional 10-inch 2-way powered loudspeaker designed for portable PA systems, live performances, DJs, musicians, installations, and mobile sound applications. Featuring a high-efficiency 1200W Class-D amplifier, EV transducer technology, and advanced QuickSmart DSP processing, the ELX200-10P delivers powerful, detailed sound in a compact and lightweight design.
Equipped with an EVS-10M low-frequency driver and DH-1L titanium compression driver, the ELX200-10P provides excellent clarity, controlled bass response, and consistent coverage. The integrated QuickSmart DSP system offers speaker presets, EQ control, crossover settings, limiter monitoring, and easy system optimisation.
Designed for both portable and installed applications, the ELX200-10P features a durable polypropylene enclosure, professional input connections, pole mount compatibility, M10 suspension points, and optional QuickSmart Mobile control for convenient wireless configuration.
Key Features
10" Two-Way System
Compact full-range design with EV low-frequency and HF drivers.
1200W Class-D Amplifier
High-efficiency amplifier delivers powerful professional output.
QuickSmart DSP
Advanced processing with presets, EQ and system monitoring.
EVS-10M Woofer
Professional 10-inch driver engineered for high performance.
Wireless Control
QuickSmart Mobile app control via Bluetooth Low Energy.
Portable Design
Lightweight cabinet with handles, pole mount and suspension points.
Technical Specifications
| Product Type | Active 2-Way Full Range Loudspeaker |
|---|---|
| Woofer Size | 10" EVS-10M Low Frequency Driver |
| High Frequency Driver | 1" DH-1L Titanium Compression Driver |
| Amplifier Type | Class-D Integrated Amplifier |
| Power Rating | 1200W |
| Frequency Response | 59Hz - 18kHz (-3dB) |
| Frequency Range | 53Hz - 20kHz (-10dB) |
| Maximum SPL | 130dB |
| Coverage Pattern | 90° x 60° |
| Crossover Frequency | 1800Hz |
| DSP Processing | QuickSmart DSP with Presets, EQ, Limiter Monitoring and System Match |
| Bluetooth Control | QuickSmart Mobile Wireless Control |
| Inputs |
2 x XLR/TRS Combo Inputs 1 x Stereo RCA Input |
| Output | 1 x XLR Link Output |
| Enclosure Material | Polypropylene Composite Cabinet |
| Grille | 18 AWG Steel Powder-Coated Grille |
| Mounting | 35mm Pole Mount + 3 x M10 Suspension Points |
| Power Supply | 100-240V AC, 50-60Hz |
| Dimensions (H x W x D) | 531 x 330 x 319mm |
| Weight | 13.5kg |
| Colour | Black |
Ideal For
- Mobile DJs
- Live Musicians
- Small Events
- Corporate Presentations
- Rehearsal Rooms
- Houses of Worship
- Education Facilities
- Portable PA Systems
- Stage Monitoring
- Installations
