ELECTRO-VOICE
ELECTRO-VOICE ELX200-18SP 18" Powered Subwoofer 1200W Black
ELECTRO-VOICE ELX200-18SP 18" Powered Subwoofer 1200W Black
Couldn't load pickup availability
ELECTRO-VOICE ELX200-18SP 18" Powered Subwoofer 1200W Black
Product Overview
The Electro-Voice ELX200-18SP is a professional 18-inch powered subwoofer designed to deliver powerful low-frequency performance for live sound, mobile DJs, musicians, venues, and portable PA systems. Featuring a high-output EVS-18L woofer, integrated 1200W Class-D amplification, and advanced DSP processing, the ELX200-18SP provides deep bass response with exceptional control and reliability.
Equipped with Electro-Voice QuickSmart DSP, the ELX200-18SP offers easy system configuration, crossover selection, EQ presets, monitoring, and professional sound optimisation. Multiple low-pass frequency options allow flexible matching with a wide range of full-range loudspeakers.
Built with a rugged plywood enclosure, durable EVCoat finish, steel grille, integrated pole mount, and professional input/output connections, the ELX200-18SP is an ideal bass extension solution for DJs, bands, touring, installations, and professional sound reinforcement systems.
Key Features
18" High Output Woofer
EVS-18L low-frequency driver for powerful deep bass.
1200W Class-D Amplifier
Efficient integrated amplification with professional output.
QuickSmart DSP
Advanced processing with presets and system optimisation.
Adjustable Crossover
Selectable low-pass frequencies for flexible system matching.
Professional Connectivity
XLR/TRS inputs with XLR link outputs for system expansion.
Touring Ready Cabinet
Strong plywood enclosure with durable EVCoat finish.
Technical Specifications
| Product Type | 18" Active Powered Subwoofer |
|---|---|
| Low Frequency Driver | EVS-18L 18" (457mm) Woofer |
| Amplifier Power | 1200W Class-D Amplifier |
| Frequency Response | 47Hz - 105Hz (-3dB) |
| Frequency Range | 40Hz - 145Hz (-10dB) |
| Maximum SPL | 132dB |
| DSP Processing | QuickSmart DSP Control |
| Low-Pass Frequency | Adjustable 80Hz / 100Hz / 120Hz / 150Hz |
| Inputs | 2 x XLR/TRS Combo Inputs |
| Outputs | 2 x XLR Link Outputs |
| Enclosure Material | 15mm Plywood with EVCoat Finish |
| Grille | 18 AWG Steel with Powder Coat Finish |
| Mounting | Integrated M20 Threaded Pole Mount |
| Power Supply | 100-240V AC, 50-60Hz |
| Dimensions (H x W x D) | 600 x 507 x 574mm |
| Weight | 29kg |
| Colour | Black |
Ideal For
- Mobile DJs
- Live Bands
- Concert Events
- Wedding Production
- Touring Systems
- Professional Venues
- Corporate Events
- Houses of Worship
- Portable PA Systems
- Sound Reinforcement
