Product Overview
The Electro-Voice EVOLVE 90 is a powerful professional column loudspeaker system designed for DJs, live performers, bands, production companies, event organisers, venues, and demanding portable PA applications. Combining a high-output 18-inch subwoofer with an eight-driver column array, the EVOLVE 90 delivers deep low-frequency extension, high acoustic output, wide coverage, and exceptional clarity in a portable three-piece system.
The column array features eight 4.7-inch neodymium drivers, providing broad horizontal coverage and controlled vertical dispersion. Advanced FIR processing provides linear frequency response and phase alignment, while the 18-inch subwoofer delivers extended, powerful bass through its high-efficiency laminar-flow vent design.
With a 2,000W amplifier system, high maximum SPL, integrated DSP, Bluetooth Stereo streaming, QuickSmart Link connectivity, and comprehensive analogue and digital inputs, the EVOLVE 90 provides a complete professional sound reinforcement solution. Its lightweight column design and 3-2-1 assembly system make setup and transportation fast and practical for mobile productions and events.
Key Features
2,000W Amplifier System
High-output amplification designed to deliver powerful and consistent performance for professional applications.
18" High-Output Subwoofer
Large-format 18-inch woofer provides deep, powerful low-frequency reproduction for demanding applications.
8 x 4.7" Neodymium Drivers
Column array delivers clear mid/high-frequency reproduction with wide, consistent coverage.
High Maximum SPL
High-output performance suitable for large events, live performances and professional sound reinforcement.
Advanced DSP & FIR Processing
Digital processing provides system optimisation, phase alignment and comprehensive loudspeaker control.
Bluetooth Stereo & QuickSmart Link
Wireless stereo streaming and system connectivity with Electro-Voice QuickSmart control technology.
Technical Specifications
| Product Type | Powered Column Loudspeaker System |
|---|---|
| Model | EVOLVE 90 |
| Colour | Black |
| Column Array | 8 x 4.7" Neodymium Drivers |
| Subwoofer | 1 x 18" Woofer |
| Amplifier Rating | 2,000W |
| LF Amplifier Power | 1,000W |
| HF Amplifier Power | 1,000W |
| Frequency Response (-3dB) | 35Hz - 18kHz |
| Frequency Range (-10dB) | 28Hz - 20kHz |
| Maximum SPL | 134dB |
| Coverage Pattern | 120° Horizontal x 25° Vertical |
| Crossover Frequency | 160Hz |
| DSP Processing | Advanced FIR Processing, Phase Alignment, DSP System Processing |
| System Control | QuickSmart Mobile App, QuickSmart Link |
| Bluetooth | Bluetooth Stereo with True Wireless Stereo |
| Microphone / Line Inputs | 2 x XLR/TRS Combo Inputs |
| Phantom Power | 48V Switchable Phantom Power |
| Stereo Line Input | XLR/TRS Combo and RCA |
| Digital Input | AES/EBU Digital Input |
| AES/EBU Thru | XLR Digital Thru Output |
| Mix Output | XLR Mix Out |
| Subwoofer Output | XLR Sub Out |
| QuickSmart Link | RJ45 QuickSmart Link Connector |
| Power Connector | PowerCON |
| Power Supply | 100 - 240VAC, 50 - 60Hz |
| Subwoofer Construction | Plywood with Polyurea Coating |
| Column Construction | Composite Material |
| Distance Pole | Aluminium |
| Grille | Steel with Protective Finish |
| System Assembly | 3-2-1 Rapid Assembly System |
| System Dimensions | Manufacturer Specified |
| System Weight | Manufacturer Specified |
Ideal For
- Professional DJs
- Live Performances
- Live Bands
- Large Events
- Wedding Events
- Corporate Events
- Production Companies
- Event Organisers
- Hotels & Venues
- Restaurants & Bars
- Large Portable PA Systems
- Professional Sound Reinforcement
