LINEA Research 88 C20 8-Channel DSP Power Amplifier
Product Overview
The LINEA Research 88 C20 is a high-power eight-channel DSP installation amplifier designed for demanding commercial, entertainment, hospitality, corporate AV, and professional sound reinforcement applications. Delivering up to 2,500W RMS per channel at 4 Ohms and 100V, the 88 C20 provides exceptional power density for large-scale multi-zone audio systems.
Featuring eight channels of high-performance Class-D amplification, the 88 C20 can deliver substantial continuous power across low-impedance loudspeaker systems and constant-voltage distributed audio networks. Its ability to drive all eight channels simultaneously makes it particularly suitable for large installations requiring multiple independent loudspeaker zones from a single amplifier.
The integrated 96kHz DSP provides comprehensive signal routing, equalisation, crossover filtering, delay, phase control, FIR processing, and advanced VX loudspeaker protection. Analogue and AES3 inputs are standard, while Dante and AES67 network audio are available as a factory-fitted option. Ethernet, RS232, and RS485 connectivity provide extensive control, monitoring, and system management through Linea Research System Engineer software.
Key Features
8-Channel High-Power Amplification
Eight independently controlled channels for large multi-zone professional audio installations.
2,500W RMS per Channel
Up to 2,500W RMS per channel at 4 Ohms and 100V with all eight channels driven.
20,000W Total Output
Up to 20,000W RMS total output across all eight channels.
96kHz DSP Processing
Advanced digital signal processing for precise routing, EQ, crossover and loudspeaker management.
100V Distributed Audio
Up to 2,500W RMS per channel for high-power constant-voltage distributed loudspeaker systems.
Advanced VX Limiters
Comprehensive peak, RMS, excursion and multiband loudspeaker protection.
Technical Specifications
| Product Type | 8-Channel DSP Installation Power Amplifier |
|---|---|
| Model | 88C20 |
| Number of Output Channels | 8 |
| Amplifier Topology | Linea Research High-Performance Class-D |
| Total Power Output | 20,000W RMS, All Channels Driven |
| Output Power @ 2 Ohm | 1,500W RMS per Channel |
| Output Power @ 4 Ohm | 2,500W RMS per Channel |
| Output Power @ 8 Ohm | 1,500W RMS per Channel |
| Bridged Output @ 4 Ohm | 3,000W RMS per Channel Pair |
| Bridged Output @ 8 Ohm | 5,000W RMS per Channel Pair |
| 100V Line Output | 2,500W RMS per Channel |
| 70V Line Output | 1,937W RMS per Channel |
| 25V Line Output | 625W RMS per Channel |
| Dynamic Range - Analogue | >113dBA Typical |
| Dynamic Range - AES3 / Dante | >114dBA Typical |
| Gain | 32dB |
| Frequency Response | <7Hz to >30kHz, 4 Ohm Load, -2.5dB Points |
| Total Harmonic Distortion | <0.05% Typical @ 1kHz, AES17 Filter, 4 Ohm Load |
| Inter-Channel Crosstalk | Better Than -85dBr @ 1kHz; Better Than -75dBr @ 10kHz |
| Slew Rate | >60V per Microsecond Typical |
| Damping Factor | >800 at Amplifier Output, Ref. 8 Ohm |
| Maximum Analogue Input Level | +20dBu |
| Analogue Input Sensitivity | 0dBu to +20dBu, Continuously Adjustable |
| Analogue Inputs | 8 x Electronically Balanced, 20k Ohm |
| AES3 Inputs | 2 Audio Channels |
| Dante / AES67 Inputs | 8 Network Audio Channels, Factory-Fitted Option |
| DSP Resolution | 40-Bit Proprietary Linea Research Processing |
| DSP Sample Rate | 96kHz |
| DSP Input Routing | 8 Analogue, 2 AES3, 8 Dante / AES67 Inputs |
| Input Processing | Signal Routing, Delay, Gain, HPF, Phase, Mute, 2 x Low Shelf, 6 x PEQ / Band Pass, FIR Shelving Filters |
| Output Processing | Source, Delay, Gain, Phase, Mute, Crossover Filters, VX Limiters, Low Shelf, 8 x PEQ / Band Pass, Shelving Filters |
| Crossover Filters | Hardman, LIR Linear Phase, Conventional Filter Shapes |
| Loudspeaker Protection | VX Limiter Suite, Peak, RMS, Excursion, Multiband Limiting |
| FIR Support | 48kHz and 96kHz FIR Files, Supported Models |
| Preset Management | 20 Device Snapshots; 50 Loudspeaker Presets |
| EQ Overlays | 12 Additional Independent EQ, Delay and Gain Overlays |
| Network Control | Ethernet Network |
| Serial Control | RS232 & RS485 |
| Alarm / Control Interfaces | Volt-Free Relay, Contact Closure, Heartbeat System Health Output |
| Power-Save Modes | Standby; Deep ECO Sleep |
| System Wake-Up | Network Command, Audio Detection, Contact Closure |
| Power Supply | 85V - 240V Auto-Sensing |
| Mains Frequency | 47Hz - 63Hz |
| Cooling | Temperature-Controlled Variable-Speed Fans |
| Airflow | Front to Rear |
| Form Factor | 2U / 19-inch Rack Mount |
| Control Software | Linea Research System Engineer |
| Manufacturing | Designed and Manufactured in the UK |
Ideal For
- Large Commercial Installations
- Large-Scale Multi-Zone Audio
- Hotels & Resorts
- Nightclubs
- Entertainment Venues
- Large Restaurants & Bars
- Retail Audio Systems
- Corporate AV Systems
- 100V Distributed Audio
- High-Power Low-Impedance Systems
- Professional Sound Reinforcement
- Large Fixed Installations
