MARTIN AUDIO XP118 Blackline XP 18" Powered Subwoofer - 2,000W Black
Product Overview
The Martin Audio Blackline XP118 is a compact, high-performance powered subwoofer designed to deliver powerful and extended low-frequency performance for professional portable sound reinforcement. Featuring an 18-inch long-excursion driver with a 4-inch voice coil and 2,000W of Class-D peak amplification, the XP118 provides substantial low-frequency impact from a compact enclosure.
Designed to complement the BlacklineX Powered XP12 and XP15 loudspeakers, the XP118 extends the combined system's low-frequency operating range to 42Hz. Four large-area reflex ports help reduce turbulent airflow noise at high output levels, while onboard DSP provides crossover, EQ, metering and system control functions.
The XP118 combines professional DSP control with a durable birch/poplar plywood enclosure, perforated steel grille, integrated ergonomic handles and a 35mm pole-mount socket. It can be used individually, stacked, or flown using its integral M10 mounting inserts, making it suitable for mobile DJs, live music, corporate AV, venues and portable PA systems.
Key Features
2,000W Class-D Amplification
High-efficiency Class-D amplification delivers 2,000W peak output to the 18-inch driver.
18" Long-Excursion Driver
Large 18-inch driver with a 4-inch voice coil provides powerful and extended low-frequency reproduction.
Onboard DSP
Integrated DSP provides crossover, EQ, metering, presets and system control through the rear-panel interface.
137dB Peak SPL
High maximum acoustic output provides substantial low-frequency impact for professional applications.
Bluetooth Control & Streaming
Optional Bluetooth functionality provides convenient wireless control and audio streaming.
Road-Ready Construction
Durable plywood enclosure, perforated steel grille, ergonomic handles and integrated mounting points.
Technical Specifications
| Product Type | Compact Self-Powered Subwoofer |
|---|---|
| Model | Blackline XP118 |
| Driver | 1 x 18" (460mm) Long-Excursion Driver |
| Voice Coil | 4" (100mm) |
| Magnet | Ferrite Magnet |
| Frequency Response | 42Hz - 150Hz ±3dB |
| Low-Frequency Extension | -10dB @ 38Hz |
| Maximum SPL | 131dB Continuous / 137dB Peak |
| Dispersion | Omnidirectional |
| Crossover | 100Hz Active |
| Amplifier Type | Class-D, Bridged Tied |
| Peak Amplifier Power | 2,000W Total |
| Average Amplifier Efficiency | 89% |
| Cooling | Convection |
| Audio Inputs | 2 x Female XLR / 1/4" Jack Combo |
| Microphone / Line Input Impedance | 8kΩ Balanced |
| 1/4" Jack TS Input Impedance | 1MΩ Unbalanced |
| Mix Output | 1 x Male XLR |
| Mix Output Impedance | 600Ω Balanced |
| Input Channel EQ | 3-Band EQ |
| Speaker EQ | 2 Presets - XP118 with XP12 / XP118 with XP15 |
| DSP Functions | Crossover, EQ, Metering, Preset Selection, System Control |
| Protection | Peak Limiting, RMS Limiting, Amplifier Thermal Protection |
| Bluetooth | Optional Bluetooth Control & Streaming |
| Power Supply | Switch-Mode with Power Factor Correction |
| AC Input Operating Range | 100 - 240V AC, 50 - 60Hz |
| Power Factor | >0.98 |
| Nominal Power Consumption | 1,000W Maximum |
| Mains Connector | 3-Pin IEC |
| Enclosure | Birch / Poplar Plywood |
| Finish | Black Textured Paint |
| Protective Grille | Black Perforated Steel |
| Mounting | 16 x M10 Inserts, 35mm Pole-Mount Socket |
| Handles | 2 x Ergonomic Side Handles |
| Castor Provision | Provision for Optional Castors |
| Dimensions (W x H x D) | 662 x 536 x 640mm |
| Dimensions (W x H x D) | 26.1 x 21.1 x 25.2" |
| Weight | 44kg / 97lbs |
Ideal For
- Mobile DJs
- Portable Sound Reinforcement
- Live Music Clubs
- Nightclubs
- Bars & Restaurants
- Corporate AV
- Hotels & Casinos
- Weddings & Parties
- House of Worship
- Rehearsal Studios
- Live Performances
- Professional PA Systems
