RCF ART 745-A MK5 1400W Active Speaker
Product Overview
The RCF ART 745-A MK5 is a flagship professional active loudspeaker designed for live performances, DJs, touring applications, rental companies, clubs, and high-quality portable PA systems. Combining RCF's advanced transducer technology with a powerful 1400W amplifier, the ART 745-A MK5 delivers outstanding clarity, high output, and reliable performance in demanding environments.
Featuring a 15-inch neodymium woofer and a 4-inch titanium diaphragm neodymium compression driver, the ART 745-A MK5 provides exceptional vocal projection, deep controlled bass, and smooth high-frequency detail. RCF FiRPHASE DSP technology provides accurate phase response, while XBOOST enhances low-frequency performance for powerful sound.
Built with a lightweight composite cabinet, professional DSP processing, XLR connectivity, pole mounting capability, and integrated M10 rigging points, the ART 745-A MK5 is ideal for DJs, musicians, live events, theatres, corporate productions, and professional sound reinforcement.
Key Features
2-Way Active System
Professional full-range loudspeaker with powerful output.
1400W Peak Power
High-efficiency Class-D amplification for live applications.
15" Neodymium Woofer
Deep bass response with precise low-frequency control.
4" Compression Driver
Titanium diaphragm neodymium driver for vocal clarity.
FiRPHASE DSP
Advanced processing for natural and accurate sound.
XBOOST Enhancement
Improved low-frequency performance and bass impact.
Technical Specifications
| Product Type | Active 2-Way Professional Loudspeaker |
|---|---|
| Low Frequency Driver | 15" Neodymium Woofer, 3.5" Voice Coil |
| High Frequency Driver | 1.4" Neodymium Compression Driver, 4" Voice Coil |
| HF Diaphragm | Titanium Diaphragm |
| Amplifier Type | Class-D Digital Amplifier |
| Total Power | 1400W Peak |
| Low Frequency Power | 1000W Peak |
| High Frequency Power | 400W Peak |
| Frequency Response | 45Hz - 20kHz |
| Maximum SPL | 133dB |
| Coverage Pattern | 90° Horizontal x 60° Vertical |
| Horn Type | Wide Dispersion Constant Directivity Horn |
| DSP Processing | FiRPHASE Technology, DSP Crossover, Equalisation, Phase Control and Protection |
| Crossover Frequency | 650Hz |
| Inputs | XLR / Jack Balanced Inputs |
| Output | XLR Link Output |
| Controls | Volume / Boost / MIC-Line Selection |
| Protection | Thermal Protection, RMS Limiter, Soft Limiter |
| Cooling | Convection Cooling |
| Power Connection | VDE Connection |
| Rigging | 2 x M10 Rigging Points |
| Mounting | 35mm Pole Mount / Floor Monitor Position |
| Enclosure Material | PP Composite Cabinet |
| Dimensions (H x W x D) | 708 x 437 x 389mm |
| Weight | 18.8kg |
| Colour | Black |
Ideal For
- Professional DJs
- Live Bands
- Touring Events
- Wedding & Mobile DJs
- Concert Venues
- Rental Companies
- Corporate Events
- Theatres
- Portable PA Systems
- Stage Monitoring
