SENHISER EW-DX EM 4 DANTE QUAD 19" Wireless Receiver 1U (S1-10) CH38

SENNHEISER EW-DX EM 4 DANTE QUAD 19" Wireless Receiver 1U (S1-10) CH38

Product Description

The Sennheiser EW-DX EM 4 DANTE is a professional four-channel digital wireless receiver designed for advanced live sound, broadcast, theatre, corporate events, houses of worship, and large-scale production environments. Built as a 19-inch 1U rackmount unit, the EW-DX EM 4 DANTE combines reliable UHF digital transmission, Dante networking, advanced remote management, and exceptional audio performance for demanding multi-channel wireless systems. (Sennheiser)

Featuring four independent receiver channels, integrated Dante digital audio output, and a rugged metal chassis, the EW-DX EM 4 DANTE provides seamless integration into modern digital audio networks. The S1-10 frequency variant operates within the 606.2–693.8MHz range (subject to local regulations), offering up to 88MHz switching bandwidth and highly efficient frequency coordination with equidistant channel spacing for large wireless deployments. (Sennheiser)

The receiver incorporates Sennheiser's proprietary SePAC codec technology, delivering 1.9ms system latency, a 141dB input dynamic range, and clear, distortion-free audio transmission. With AES-256 encryption, integrated antenna distribution, four configurable network ports, and compatibility with Sennheiser Control Cockpit and SoundBase software, the EW-DX EM 4 DANTE is designed for professional installations where reliability, scalability, and remote control are essential. (Sennheiser)

Key Features

• Four-channel digital full-rack (19") wireless receiver

• Dante-enabled digital audio output

• S1-10 frequency range (606.2–693.8MHz)

• Up to 88MHz switching bandwidth

• Up to 293 compatible channels using Link Density mode

• Ultra-low 1.9ms system latency

• 141dB input dynamic range with SePAC codec technology

• Integrated antenna splitter with cascading capability

• AES-256 encrypted wireless transmission

• Four configurable network ports for Dante and control

• OLED display with jog wheel navigation

• Remote management via Sennheiser Control Cockpit, Wireless System Manager and Smart Assist App

• Supports up to four EW-DX EM 4 DANTE units in RF daisy-chain configuration

Specifications

• System Type: Digital UHF Wireless Receiver

• Receiver Format: Quad Channel Full Rack 19" / 1U

• Channels: 4 Independent Receiver Channels

• Frequency Band: S1-10

• Frequency Range: 606.2 – 693.8MHz

• Transmission Technology: Digital UHF

• Codec: Sennheiser Performance Audio Codec (SePAC)

• System Latency: 1.9ms

• Dynamic Range: 134dB / 141dB Input Dynamic Range

• Audio Frequency Response: 20Hz – 20kHz (-3dB)

• Dante Output: RJ45 Dante Digital Audio Output (48kHz / 96kHz, 24-bit)

• Analogue Outputs: Balanced Audio Outputs

• Network Connectivity: Ethernet with IPv4/IPv6 Support

• Encryption: AES-256 Encryption

• Antenna Connections: Integrated Antenna Splitter with RF Loop Through

• Daisy Chain: Up to 16 Channels (4 x EW-DX EM 4 DANTE)

• Headphone Output: 2 x 70mW @ 32Ω

• Power Supply: Internal Auto-Switching PSU (90–265V AC)

• Power Consumption: Max. 37W

• Operating Temperature: -10°C to +55°C

• Dimensions (W x H x D): 483 x 44 x 373mm

• Rack Size: 19" / 1U

• Weight: Approx. 4.56kg (without antennas and PSU) (Sennheiser)

Ideal For

• Professional Touring Productions

• Broadcast & Television

• Large Corporate Events

• Theatres & Performing Arts Venues

• Houses of Worship

• Rental & Hire Companies

• Conference & Presentation Systems

• Live Music Venues

• Multi-Microphone Wireless Installations

• Professional Dante-Based Audio Networks

• Large-Scale Live Sound Reinforcement (Sennheiser)
