SHURE
SHURE BLX24R/SM58 Wireless Rackmount Handheld System BLX4R/SM58 K3E
SHURE BLX24R/SM58 Wireless Rackmount Handheld System BLX4R/SM58 K3E
Couldn't load pickup availability
SHURE BLX24R/SM58 Wireless Rackmount Handheld System BLX4R/SM58 K3E
Product Overview
The Shure BLX24R/SM58 is a professional rackmount wireless handheld microphone system designed for live performance, touring, events, houses of worship, and professional audio installations. Combining the trusted Shure SM58 vocal microphone capsule with the reliable BLX wireless platform, this system delivers clear vocals, dependable wireless operation, and easy setup.
Featuring the BLX4R rackmount receiver and BLX2 handheld transmitter with the legendary SM58 cardioid dynamic capsule, the system provides excellent vocal clarity, reduced background noise, and strong feedback rejection. The rugged receiver design makes it ideal for permanent installations and touring rack systems.
Operating on the K3E frequency band, the BLX24R/SM58 offers up to 100 metres of wireless range, up to 14 hours of battery life, and professional features including QuickScan frequency selection, detachable antennas, and rack mounting capability.
Key Features
SM58 Capsule
Industry-standard vocal microphone with clear sound and feedback rejection.
Rackmount Receiver
BLX4R receiver designed for professional rack installations.
Reliable Wireless
Up to 100m operating range with stable UHF transmission.
Quick Setup
One-touch QuickScan frequency selection for fast configuration.
Long Battery Life
Up to 14 hours of operation using AA batteries.
Professional Use
Ideal for touring, events, venues, and installations.
Technical Specifications
| System Type | Wireless Rackmount Handheld Microphone System |
|---|---|
| Wireless Technology | Analogue UHF |
| Frequency Band | K3E |
| Frequency Range | 606 – 648MHz |
| Receiver Model | BLX4R Rackmount Receiver |
| Transmitter Model | BLX2 Handheld Transmitter |
| Microphone Capsule | Shure SM58 Dynamic Capsule |
| Polar Pattern | Cardioid |
| Frequency Response | 50Hz – 15kHz |
| RF Output Power | 10mW |
| Operating Range | Up to 100m (Line of Sight) |
| Battery Type | 2 x AA Batteries |
| Battery Life | Up to 14 Hours |
| Receiver Outputs | XLR Balanced + 6.35mm Jack Output |
| Antenna Connections | Detachable BNC Antennas |
| Rack Mounting | 19" Rackmount Kit Included |
| Receiver Dimensions | 198 x 166 x 39mm |
| Receiver Weight | Approx. 998g |
| Colour | Black |
Ideal For
- Live Vocal Performers
- Touring Productions
- Music Venues
- Corporate Events
- Houses of Worship
- Theatres
- Conference Systems
- Rental & Hire Companies
- Professional AV Installations
- Live Sound Reinforcement
