YAMAHA MG12 12-Channel Mixing Console 6 Mic / 12 Line with Faders
YAMAHA MG12 12-Channel Mixing Console 6 Mic / 12 Line with Faders
Couldn't load pickup availability
YAMAHA MG12 12-Channel Mixing Console 6 Mic / 12 Line with Faders
Product Overview
The Yamaha MG12 is a professional 12-channel analogue mixing console designed for live sound, installations, rehearsals, and portable PA applications. Featuring up to 6 microphone inputs, 12 line inputs, Yamaha D-PRE microphone preamps, and a practical analogue workflow, the MG12 delivers clean, reliable sound with precise hands-on control. :contentReference[oaicite:0]{index=0}
Designed for engineers and performers who require straightforward operation, the MG12 features 1-knob compressors, 3-band EQ, AUX sends, group buses, and smooth channel controls for fast and efficient mixing in any environment. :contentReference[oaicite:1]{index=1}
With a rugged metal chassis, +48V phantom power, XLR balanced outputs, internal universal power supply, and optional rack mounting, the Yamaha MG12 is an ideal choice for bands, venues, houses of worship, corporate events, and professional sound systems. :contentReference[oaicite:2]{index=2}
Key Features
12-Channel Mixer
Professional analogue mixing with flexible inputs.
D-PRE Preamps
High-quality microphone preamps with natural sound.
60mm Faders
Accurate level control for live mixing.
1-Knob Compressors
Simple dynamic control on input channels.
Flexible Routing
Group buses and AUX sends for monitoring.
Rack Ready
Suitable for installations and touring setups.
Technical Specifications
| Product Type | Analogue Mixing Console |
|---|---|
| Total Channels | 12 Channels |
| Microphone Inputs | Maximum 6 Mic Inputs |
| Line Inputs | 12 Line Inputs |
| Input Configuration | 4 Mono Mic/Line Inputs + 4 Stereo Inputs |
| Microphone Preamps | Yamaha D-PRE Preamps with Inverted Darlington Circuit |
| Channel EQ | 3-Band EQ with High-Pass Filtering |
| High-Pass Filter | 80Hz High-Pass Filter |
| Compressor | 1-Knob Compressor on Mono Channels |
| Faders | 60mm Channel Faders |
| Group Buses | 2 Group Buses + 1 Stereo Bus |
| AUX Sends | 2 AUX Sends |
| Phantom Power | +48V Phantom Power |
| Outputs | XLR Balanced Stereo Outputs |
| PAD Switch | Available on Mono Inputs |
| Effects Processor | No Built-In Effects |
| USB Interface | No USB Audio Interface |
| Construction | Metal Chassis |
| Power Supply | Internal Universal Power Supply |
| Rack Mounting | Optional RK-MG12 Rack Mount Kit |
| Dimensions (W x H x D) | 308 x 118 x 422mm |
| Weight | 4.0kg |
| Colour | Black |
Ideal For
- Live Bands
- Small Venues
- Houses of Worship
- Corporate Events
- Theatre Productions
- Rehearsal Spaces
- Mobile PA Systems
- Touring Applications
- Installation Projects
- Professional Sound Engineers
