YAMAHA MGX12 B 12-Channel Digital Mixing Console 4 Combo Line Black
Product Overview
The Yamaha MGX12 B is a compact digital mixing console designed to provide professional audio performance, intuitive control, and versatile connectivity in a portable format. Featuring 12 input channels, 4 combo microphone/line inputs, built-in DSP processing, USB recording, and Bluetooth audio, the MGX12 B is ideal for live sound, content creation, installations, and mobile productions. :contentReference[oaicite:0]{index=0}
Equipped with a 4.3-inch touchscreen, 12-channel fader layout, and Yamaha's advanced digital processing tools, the MGX12 B provides fast setup and easy operation while maintaining professional sound quality. Features including Auto Gain, Clip Safe, Scene Recall, and flexible effects processing make it suitable for a wide range of applications. :contentReference[oaicite:1]{index=1}
With USB audio connectivity, microSD recording, Bluetooth playback, and multiple output options, the MGX12 B delivers a complete mixing solution for performers, venues, streamers, and production environments requiring a compact yet powerful mixer. :contentReference[oaicite:2]{index=2}
Key Features
12-Channel Mixer
Flexible digital mixing with mono, stereo and FX channels.
Touchscreen Control
4.3-inch display for quick navigation and setup.
DSP Processing
Professional EQ, dynamics and effects processing.
USB Recording
Multitrack recording and playback via USB.
Bluetooth Audio
Wireless playback with Bluetooth 5.0 connectivity.
Portable Design
Compact format for live and mobile applications.
Technical Specifications
| Product Type | Compact Digital Mixing Console |
|---|---|
| Input Channels | 4 Mono + 4 Stereo + 1 Sound Pad + 2 FX Return |
| Total Channels | 12 Channels |
| Mic / Line Inputs | 4 x Combo XLR/TRS Inputs |
| Line Inputs | 4 x TRS Line Inputs + 4 x RCA Line Inputs |
| Mix Buses | 8 Mix Buses + 1 Stereo Bus |
| FX Buses | 2 FX Buses |
| Outputs | 2 x XLR Main Outputs + 6 x TRS Outputs |
| Headphone Outputs | 4 x TRS Headphone Outputs |
| Display | 4.3-inch Touchscreen |
| Faders | 12 x 60mm Faders |
| USB Main Interface | 18 Input / 18 Output USB Audio |
| USB Sub Interface | 2 Input / 2 Output USB Audio |
| USB Resolution | 32-bit / 96kHz (Main), 16-bit / 48kHz (Sub) |
| microSD Recording | 16-Track Recording / 2-Track Playback |
| Bluetooth | Bluetooth 5.0 Audio Input (A2DP) |
| DSP Features | EQ, Compressor, Gate, Effects, Auto Gain, Clip Safe, Scene Recall |
| Built-In Effects | Reverb, Delay, Modulation, Amp Simulation and Voice Processing |
| Noise Level | -128dBu Equivalent Input Noise |
| Power Supply | External AC Power Adapter |
| Dimensions (W x H x D) | 335 x 96 x 319mm |
| Weight | 3.9kg |
| Colour | Black |
Ideal For
- Live Performances
- Bands & Musicians
- Content Creators
- Podcast Production
- Corporate Events
- Houses of Worship
- Small Venues
- Mobile Sound Engineers
- Recording Applications
- Streaming Setups
